How to fix “your model is not manifold” error in Cura

You just pulled a file from Thingiverse and now when you try to slice it in Cura it says “your model is not manifold”.  If you just want to make the error go away you can skip to the paragraph “The Fix”  if you don’t want to be “filled in” on why it’s happening in the first place. Little bit of 3D printing humour there for ya.

So what does the error mean?

For a model to be manifold you can think of it as having logically enclosed space in a manner that can exist in real life with an outer geometry that can actually be 3D printed.

So what does non-manifold mean?

There’s a couple of reasons why a model is not manifold and here they are:

  • Self-intersecting
  • Separate Object
  • Hole
  • Inner Faces
  • Overlapping Geometry

Self-intersecting: This is a bit of a weird analogy but imagine punching through yourself. You can’t do that in real life without making a big hole but in a virtual model of yourself you can have the objects of your fist and forearm pass through another body part of your choosing and that’s perfectly fine but in real life you can’t have two objects with mass occupy the same space at the same time so this cannot be printed.

Separate Object: Imagine a model of a figurine wearing sun glasses. If the sun glasses and the figurine were two separate objects and you shrank the figurine by rescaling it to 90% its original size the sun glasses might be left floating in midair. That’s fine for a virtual 3D model but in real life gravity might have something to say about that.

Hole: Pretty self explanatory, there’s a hole in the model and not like a window just a void that makes the model impossible to print successfully.

Inner Faces: Imagine trying to print a model within a model. The slicer reads the code and gets confused because there should only be one outer surface area not two.

Overlapping Geometry: Imagine you have created a 3D model of a house and you’ve accidentally copied the roof and then pasted it back on top of the model over the original roof. The model now has two roofs occupying the same space which cannot be printed.

The Fix:

Ideally you should open the file with some 3D modelling software and fix it manually but if you’re just pulling files from Thingiverse that’s a bit unrealistic. Luckily the following site allows you to upload files and it will try to fix them automatically.

https://3d-print.jomatik.de/en/index.php

If the process successfully fixes the file it will give you the option to download the file with a brief summary of what changes it made highlighting big changes in red.

Its a great solution especially for low risk models but the onus will always be on you to manually inspect the model to see if the problems have in fact been resolved. Also if you’re working on a super secret product design for a company probably best not to upload the model to be fixed online, but for files you’ve pulled from Thingiverse sure why not they’re already publicly available anyway.

How to use a generic PC controller with GTA 5

So you plugged in the cheap PC controller you bought off eBay or Amazon (say one that is coincidentally shaped like an Xbox controller) and found it doesn’t work with GTA 5?

This is probably because the controller is using the DirectInput standard as opposed to the newer XInput standard. You can read more about these standards from Microsoft by clinking on this link.

GTA 5 (or GTA V if you’re feeling fancy) was not optimised to use the DirectInput standard unfortunately. However if you’re playing the game on PC you should be using a keyboard and mouse like a grown-up anyway, it’s way better for shooters. Ah but GTA isn’t all about the shooting I hear you say and you’re right. I’ll admit I switch to a controller for flying vehciles because they are horrible to pilot with direction keys. Analogue sticks are much better suited to aircraft.

So the workaround for being able to use the cheap generic controller is quite simple but requires using an “Xbox 360 Controller Emulator”.

Download the file x360ce_x64 from the following site by clicking on the “download for 64 bit games” button at the top of the screen.

https://www.x360ce.com/

(Be sure to test the downloaded file with whatever antivirus software you have installed)

Once you are satisfied the software is safe extract the file to the root directory of where you installed GTA 5.

(If you do not know where that folder is try searching GTAV in your Windows search bar. Note a folder called GTA V is often created in the Documents folder but this is not the correct directory.  The correct directory will have application files with the GTAV logo in it. The game maybe in a Rockstar folder or perhaps a Steam or Epic folder, it all depends on who you bought it from.)

Right click on x360ce_x64 and run the file as administrator and you should be given an option button to “Create”.

Click this button and a Xbox controller calibration window will open.

At this point if your controller has a large circular button at its center press it and make sure it lights up otherwise it may not send the right signals when the controller is being mapped.

Click “Auto” and then “Save”.

I found the A, B, X and Y face buttons were not mapped correctly and needed to be mapped manually.

To do this, beside each face button on the emulator interface there is a drop down menu. Click on it for each button and choose the option to record. The interface will highlight which button to press on your controller to map it correctly. Once the buttons are mapped correctly click “Save” again.

After following these steps you should now be able to play GTA V with the controller.

How to secure Creality Ender 3 Pro TL-Smoothers once installed

This post will outline how to secure TL-Smoothers within the Creality Ender Pro circuit housing without blocking vents.

Prerequisites:

You will need insulation tape and double-sided sellotape to following the instructions.

What are TL-Smoothers?

A TL-Smoother, as displayed below, is an add-on circuit module for 3D printer stepper motor drivers. They seek to lower vibration, lower noise and provide a smoother result by way of cleaning up electrical signals. Their use is intended to compensate for less than premium motor control circuits that are used in more budget 3D printers.

TL-Smoother

(Note: there is an ongoing debate as to whether TL-Smoothers have any benefit on print quality for the Ender 3 Pro. This post will not cover this topic or the installation process as a whole. This post simply puts forth advice regarding good placement and how to secure the circuits.)

Steps:

The four pin sockets of the TL-Smoothers protrude on the back side of the circuit.

Clip the ends off of these protrusion using the electrical wire cable cutters, provided with the printer, leaving the back of each circuit flat.

Cover the four pins on either end of each circuit with insulation tape, this will prevent shorts.

Cut a small square of double-sided tape and secure it to the back of each circuit as shown below.

DoubleSidedTapeSmall



Secure the circuits as demonstrated below using the double-sided tape. These locations will ensure everything will fit inside the housing while leaving enough space for the fan. The green square in the picture marks where the fan will be situated when the housing is closed back up.



Smoother Placement

Happy Printing. ☮



How to create a console application in C# that will solve crosswords

This tutorial will cover the following tasks in C#:

  • How to count the characters in a string
  • How to assign a file’s directory location to a variable
  • How to create a list variable
  • How to pull/read a CSV file column into a list variable
  • How to clean strings using Regex to remove non alpha numeric characters as the strings are being read into a list
  • How to remove duplicate word entries from a list
  • How to order a list
  • How to write variables to the console, including a list’s elements

Assumptions:

You already know how to create projects in Visual Studio.

If you do not how to do this search online using the following term “how to create C# console applications in visual studio”.

Prerequisites:

First you will need to generate a CSV file with random words using this site:

https://onlinerandomtools.com/generate-random-csv

For the option “how many columns to generate” set the value to 1.

For testing purposes create 1000 rows.

Download the csv file generated and save it using the name “words”.

Summary of how the code works:

The code works by reducing the initial list (i.e. the supplied CSV file of random words) down to only words that match the number of characters of the user word, typically referred to as “string length”.

Once that subset of words has been created the code will then compare the user word’s letters against each letter, referencing the relative position, in each word in the subset.

Note: there is still significant room for optimization but the code is functional and works well as an accessible, human readable tutorial.

Use case example:

If the user enters the word “apple” the dictionary subset will be reduced down to 5 letter words only. These five letter words are then compared to the user word, each word and letter at a time. So if the first word in the list was “cabin” the comparison would jump to the next word in the list as the “a” in “apple” does not match the “c” in “cabin”. If the next word in the dictionary was “acorn” the first letters would match but the comparison would jump to the next word when the “c” and “p” did not match.

Instructions:

Create a C# console application called CrosswordSolver in Visual Studio.

Move the CSV file called “Words” into the bin directory of the project folder, i.e. CrosswordSolver\CrosswordSolver\bin

Open the project CrosswordSolver and paste the C# code below into the default window replacing the default cs page code.

The hardcoded example of a user word is:

string userWord = “a****”;

The user can use * to represent characters unknown, for example ap*le.

Note: The CSV file you randomly generated may have no examples of 5 letter words begining with the letter “a” so experiment with other characters.

You can test the letter comparison functionality by uncommenting the two sections of code immediately following the comments “Test letter comparison”.

To test your CSV file has been read into memory you can uncomment the section of code immediately following “Test that dictionary has been read into memory”.

The C# code:

using System;
using System.IO;
using System.Linq;
using System.Collections.Generic;
using System.Text.RegularExpressions;

namespace CrosswordSolver
{
    class Program
    {
        static void Main(string[] args)
        {
            int c = 0;
            //User input
            //NOTE: Use * to represent characters unknown
            string userWord = "a****";
            int wordLength = userWord.Length;

            //Assign directory location of the csv file containing the collection of words to a variable
            string projectFolder = Directory.GetParent(Directory.GetCurrentDirectory()).Parent.FullName;
            string file = Path.Combine(projectFolder, "words.csv");

            //Display dictionary location in console
            Console.WriteLine("Dictionary location: " + file);

            var dictionary = new List<string>();
            using (var rd = new StreamReader(file))

            //Pull file column into dictionary list without cleaning
            //{
            //    while (!rd.EndOfStream)
            //    {
            //        var splits = rd.ReadLine().Split(',');
            //        dictionary.Add(splits[0]);
            //    }
            //}

            //Pull file column into dictionary list while cleaning
            {
                while (!rd.EndOfStream)
                {
                    var splits = rd.ReadLine().Split(',');
                    //string clean is done with Regex
                    dictionary.Add(Regex.Replace(splits[0], "[^A-Za-z0-9 ]", ""));
                }
            }

            //Test that dictionary has been read into memory
            //Console.WriteLine("The dictionary contains the following words:");
            //foreach (var element in dictionary)
            //Console.WriteLine(element);

            //Remove duplicate word entries
            //c = dictionary.Count;
            //Console.WriteLine("The dictionary contains " + c + " words");
            dictionary = dictionary.Distinct().ToList();
            //c = dictionary.Count;
            //Console.WriteLine("The dictionary contains " + c + " words");

            // Count the elements in the List and display test parameters
            c = dictionary.Count;
            Console.WriteLine("The dictionary contains " + c + " words");
            Console.WriteLine("User entered the string: " + userWord);
            Console.WriteLine(userWord + " has " + wordLength + " characters");
            userWord = userWord.ToLower();

            //Reduce the dataset size based on number of characters in string
            IEnumerable<string> query =
                dictionary.Where(word => word.Length == wordLength);

            var subSet = new List<string>();
            foreach (var word in query)
                subSet.Add(word);

            //Order List
            subSet = subSet.OrderBy(x => x).ToList();

            c = subSet.Count;
            if (c != 0)
            {
                Console.WriteLine("The dictionary contains " + c + " words that are " + wordLength + " characters in length");

                //Begin character and position match check
                var result = new List<string>();
                foreach (var word in subSet)

                {
                    for (int i = 0; i <= wordLength - 1; i++)
                    {

                        if ((word.ToLower()[i] == userWord[i]) | (userWord[i] == '*'))
                        {

                            //Test letter comparison (Letters match)
                            //Console.WriteLine(
                            //"Letter " + i + ", which is " + "\"" + word[i] + "\"" + ", of the word " + "\"" + word + "\"" +
                            //" matches letter " + i + ", which is " + "\"" + userWord[i] + "\"" + ", of the user input " + "\"" + userWord + "\""
                            //);

                            if (i == wordLength - 1)
                            { result.Add(word); }

                        }
                        else
                        {
                            //Test letter comparison (Letters do not match)
                            //Console.WriteLine(
                            //"Letter " + i + ", which is " + "\"" + word[i] + "\"" + ", of the word " + "\"" + word + "\"" +
                            //" does not match letter " + i + ", which is " + "\"" + userWord[i] + "\"" + ", of the user input " + "\"" + userWord + "\""
                            //);

                            break;
                        }
                    }
                }

                //Test words that do not match
                //foreach (var word in subSetToRemove)
                //Console.WriteLine(word);

                bool isEmpty = !result.Any();
                if (isEmpty)
                {
                    Console.WriteLine("No matches found");
                }
                else
                {
                    c = result.Count();
                    Console.WriteLine("Potential matches found: " + c);
                    foreach (var word in result)
                        Console.WriteLine(word);
                }
            }
            else
            {
                Console.WriteLine("No words of " + wordLength + " characters long found");
            }
            Console.ReadKey();
        }
    }
}



If you found this code useful be sure to like the post and comment. ☮

If you would like to know how to create a csv file with C# see this tutorial link.

If you would like to know how to create a console application in Visual Studio that won’t open a command window when it runs see this tutorial link.



How to fix the right analog stick of a generic PC controller for Fifa Online 3

Fifa Online 3 is a free version of Fifa that is popular in Asia as an esport title. The gameplay and visuals are a little dated but it’s still a solid experience at a great price. You won’t make it through the tutorials however if you are using a cheap generic PC controller (say one that is coincidentally shaped like an xbox controller) as you won’t be able to save penalties. This is because the right analog stick may not be recognised.

The fix is quite simple.

Download the file x360ce from the following site by clicking on the “download for 32 bit games” button at the top of the screen.

https://www.x360ce.com/

(Be sure to test the downloaded file with whatever antivirus software you have installed)

Once you are satisfied the software is safe extract the file to the root directory of where you installed the game. (Note: the game directory will probably not be called Fifa etc. it will likely be a series of numbers)

Open the file and you should be given an option button to “Create”.

Click this button and a Xbox controller calibration window will open.

Click “Auto” and then “Save”, and that should do it.

See the video below for a more visual guide, just don’t download the 64 bit file.

How to fix the “Fatal Error: Illegal characters in path” problem during a WSUS Installation

If your reading this you’re probably at the point of trying to install a new WSUS server on Windows Server 2012 R2 and have received the message “Fatal Error: Illegal characters in path”.

The fix is annoyingly simple.

You may have created a partition specifically for the task, i.e. created a new drive and assigned it the letter E:\, and only referenced the root of the partition assuming the installation would create whatever directories it needs, you know like every other software.

The problem is you cannot specify the root of partition alone, you need to specify a directory, or the partition name, such as E:\WSUS.

A fully qualified path should fix the problem.

What is WSUS?

Windows Server Update Services (WSUS) provides a cost-effective patch management solution to deploy updates to domain-joined Windows servers and workstation in a corporate network. WSUS is fully integrated in Windows Server 2012 and can be enabled on Windows clients by configuring settings in Group Policy Objects – GPO.

How to fix winhiip writing to hard drive problem

If you are trying to format a hard drive to be used by a PlayStation 2 you’ve probably already come across excellent content like the video below and the necessary tools to do the job.



However you might, like me, run into the problem of winhiip not being able to right to the drive which will prevent it from formatting the drive correctly.

To resolve this problem you will need to manipulate the drive in Windows “Disk Management”.

Open Disk Management (to open type disk management in Windows search and hit enter)

Find the reference to disk you want to fix and if it has not already been formatted follow these steps:

  • Initialize the disk. (If not already initialized)
  • Right click the Unallocated Space on the disk and click New Simple Volume.
  • Proceed through the New Volume Wizard, setting the Volume size to the maximum disk space and formatting the drive under the NTFS file system. (Only a quick format is needed)
  • Wait for the drive to finish formatting, then right click the healthy partition you just made and click Delete Volume.
  • Open WinHIIP and click Select Drive, then select your drive. Press OK to all errors that pop up upon loading the drive.

At this point you should be able to write to the drive with no problems.



How to list login details, such as name and role membership, for all logins in a SQL Server Instance

The script below will provide SQL Server Instance login details such as:

  • The login name
  • The role membership the login is part of such as sysadmin etc.,
  • Whether or not the login is enabled
  • Whether or not the login is a SQL Server Login or Windows Login etc.
  • Login created date
  • Login modified date
  • Etc.
SELECT SP.principal_id
	,SP.name
	,SUSER_NAME(role_principal_id) server_role
	,SP.is_disabled
	,SP.type_desc
	,SP.sid
	,SP.type
	,SP.create_date
	,SP.modify_date
	,SP.default_database_name
	,SP.default_language_name
	,SP.credential_id
	,SP.owning_principal_id
	,SP.is_fixed_role
FROM sys.server_principals AS SP
LEFT JOIN sys.server_role_members AS RM ON SP.principal_id = RM.member_principal_id;



How to set every database in a SQL Server instance to read only

The following TSQL when executed will create the TSQL needed to set all databases in a SQL Server instance to read only mode.

Typical use cases for this might include creating a copy of databases for reporting purposes or when migrating databases from one server to another.

SELECT 'ALTER DATABASE [' + NAME + '] SET SINGLE_USER WITH ROLLBACK IMMEDIATE
ALTER DATABASE [' + NAME + '] SET READ_ONLY WITH NO_WAIT
ALTER DATABASE [' + NAME + '] SET MULTI_USER
GO'
FROM sys.databases
/*Setting database id > 4 excludes the system databases*/
WHERE database_id > 4



Before you run the outputted script you may need to kill open connections to the databases or certain running activities. Obviously you would want to make sure it is safe to do so before killing any activity.

To kill activities on mass you can use the script in this post.





How to create a job that tests whether SQL Server database mail is working

The following script will create a job that will run every minute to test if database mail can be sent from a job scheduled to run by the Sql Server Agent.

Simply find and replace the email address below with the email address you want to target:

testoperator@mail.com

Then run the script.

The operator ‘Test Operator’ and job ‘MailTest’ will be created.

The job is disabled by default, enable it to begin testing.

When you are finished run the commented out section at the bottom of the script to remove the test operator and job.

If you have just setup database mail for the first time the SQL Server Agent will need to be restarted.

/*
FIND AND REPLACE

testoperator@mail.com

*/
USE msdb;
GO

EXEC dbo.sp_add_operator @name = N'Test Operator'
	,@enabled = 1
	,@email_address = N'testoperator@mail.com'
GO

USE [msdb]
GO

BEGIN TRANSACTION

DECLARE @ReturnCode INT

SELECT @ReturnCode = 0

/****** Object:  JobCategory [[Uncategorized (Local)]]    Script Date: 31/07/2019 11:35:43 ******/
IF NOT EXISTS (
		SELECT NAME
		FROM msdb.dbo.syscategories
		WHERE NAME = N'[Uncategorized (Local)]'
			AND category_class = 1
		)
BEGIN
	EXEC @ReturnCode = msdb.dbo.sp_add_category @class = N'JOB'
		,@type = N'LOCAL'
		,@name = N'[Uncategorized (Local)]'

	IF (
			@@ERROR <> 0
			OR @ReturnCode <> 0
			)
		GOTO QuitWithRollback
END

DECLARE @jobId BINARY (16)

EXEC @ReturnCode = msdb.dbo.sp_add_job @job_name = N'MailTest'
	,@enabled = 0
	,@notify_level_eventlog = 0
	,@notify_level_email = 3
	,@notify_level_netsend = 0
	,@notify_level_page = 0
	,@delete_level = 0
	,@description = N'No description available.'
	,@category_name = N'[Uncategorized (Local)]'
	,@owner_login_name = N'sa'
	,@notify_email_operator_name = N'Test Operator'
	,@job_id = @jobId OUTPUT

IF (
		@@ERROR <> 0
		OR @ReturnCode <> 0
		)
	GOTO QuitWithRollback

/****** Object:  Step [Step 1]    Script Date: 31/07/2019 11:35:44 ******/
EXEC @ReturnCode = msdb.dbo.sp_add_jobstep @job_id = @jobId
	,@step_name = N'Step 1'
	,@step_id = 1
	,@cmdexec_success_code = 0
	,@on_success_action = 1
	,@on_success_step_id = 0
	,@on_fail_action = 2
	,@on_fail_step_id = 0
	,@retry_attempts = 0
	,@retry_interval = 0
	,@os_run_priority = 0
	,@subsystem = N'TSQL'
	,@command = N'SELECT 1'
	,@database_name = N'master'
	,@flags = 0

IF (
		@@ERROR <> 0
		OR @ReturnCode <> 0
		)
	GOTO QuitWithRollback

EXEC @ReturnCode = msdb.dbo.sp_update_job @job_id = @jobId
	,@start_step_id = 1

IF (
		@@ERROR <> 0
		OR @ReturnCode <> 0
		)
	GOTO QuitWithRollback

EXEC @ReturnCode = msdb.dbo.sp_add_jobschedule @job_id = @jobId
	,@name = N'Job Schedule'
	,@enabled = 1
	,@freq_type = 4
	,@freq_interval = 1
	,@freq_subday_type = 4
	,@freq_subday_interval = 1
	,@freq_relative_interval = 0
	,@freq_recurrence_factor = 0
	,@active_start_date = 20190731
	,@active_end_date = 99991231
	,@active_start_time = 0
	,@active_end_time = 235959
	,@schedule_uid = N'f0741db6-488e-44da-8f5e-a3f0ed13835e'

IF (
		@@ERROR <> 0
		OR @ReturnCode <> 0
		)
	GOTO QuitWithRollback

EXEC @ReturnCode = msdb.dbo.sp_add_jobserver @job_id = @jobId
	,@server_name = N'(local)'

IF (
		@@ERROR <> 0
		OR @ReturnCode <> 0
		)
	GOTO QuitWithRollback

COMMIT TRANSACTION

GOTO EndSave

QuitWithRollback:

IF (@@TRANCOUNT > 0)
	ROLLBACK TRANSACTION

EndSave:
GO

/*
REMOVE OPERATOR AND JOB
*/
/*
USE msdb;
GO

EXEC sp_delete_operator @name = 'Test Operator';

EXEC sp_delete_job @job_name = N'MailTest';

GO
*/
